Electric hoist suspended Balkancarpodem

Electric suspended hoists with a lifting capacity from 1.0 to 25.0 tons.

Electric hoists are mounted (suspended) on a monorail track made of a special I-beam of the following types: 24 m, 30 m, 36 m and 45 m according to GOST 19425-74. Hoists can be used as an independent lifting mechanism or as part of a single-girder crane. There are several modifications of hoists, differing in the design of the body: round, - type 13 t / t and rectangular, - type mh / mhl.

connect with us:

Grygorii Gumyniuk

+38 (050) 381-52-70

grigori@gutman.com.ua

Download Price List buy product

Hoists with a lifting height of up to 17 meters inclusive, are equipped with one travel trolley. Hoists with a lifting height of 18 meters or more are equipped with two travel trolleys, and hoists for monorail tracks of a complex profile (non-straight) are equipped with rotary units of the travel trolleys. Possible choice: with a wired remote control or a radio remote control; various lifting and moving speeds, including multiple speeds; pulley ratio 1/1; 2/2; 2/1; 4/2; 4/1, etc.
