Features

• Max weight capacity: 50 kg
• Max working radius: 5000 mm
• Vertical lift: 1800 mm
• Working pressure: 0.7 ÷ 0.8 Mpa
• Control system: pneumatic and electric
• Supply: filtrated compressed-air (40 µm), not lubricated
• Noise level: <76 dB
• Max vertical lifting speed: 0,5 meters/second
• Working temperature: from +0° to +45° C
• Consumption: from 20 Nl ÷ 100 Nl per working cycle
• Rotations: – constant 360° on the column and tooling axis - 300° on the intermediate axis

Features

• Max weight capacity: 200 kg
• Max working radius: 4500 mm
• Vertical lift: 1900 mm
• Working pressure: 0.7 ÷ 0.8 Mpa
• Control system: solely pneumatic
• Supply: filtrated compressed-air (40 µm), not lubricated
• Noise level: <70 dB
• Max vertical lifting speed: 0,5 meters/second
• Working temperature: from +0° to +45° C
• Consumption: from 40 Nl ÷ 120 Nl per working cycle
• Rotations: – constant 360° on the column and tooling axis - 315° on the intermediate axis

Features

• Max weight capacity: 80 kg
• Max working radius: 2000 mm
• Vertical lift: 2150 mm
• Working pressure: 0.7 ÷ 0.8 Mpa
• Control system: solely pneumatic
• Supply: filtrated compressed-air (40 µm), not lubricated
• Noise level: <70 dB
• Max vertical lifting speed: 0,5 meters/second
• Working temperature: from +0° to +45° C
• Consumption: from 5 Nl ÷ 30 Nl per working cycle
• Rotations: – constant 360° on the column and tooling axis - 300° on the intermediate axis

Features

• Max weight capacity: 80 kg
• Vertical lift: 1800 mm
• Working pressure: 0.7 ÷ 0.8 Mpa
• Control system: solely pneumatic
• Supply: filtrated compressed-air (40 µm), not lubricated
• Noise level:
• Max vertical lifting speed: 0,5 meters/second
• Working temperature: from +0° to +45° C
• Consumption: from 10 Nl ÷ 20 Nl per working cycle
• Rotation: 360° on tooling axis

Features

• Max weight capacity: 140 kg
• Max working radius: 3000 mm
• Vertical lift: 1800 mm
• Working pressure: 0.7 ÷ 0.8 Mpa
• Control system: solely pneumatic
• Supply: filtrated compressed-air (40 µm), not lubricated
• Noise level: <70 dB
• Max vertical lifting speed: 0,5 meters/second
• Working temperature: from +0° to +45° C
• Consumption: from 20 Nl ÷ 100 Nl per working cycle
• Rotations: – constant 360° on the column and tooling axis - 300° on the intermediate axis

Features

• Max weight capacity: 60 kg
• Max working radius: 2600 mm
• Vertical lift: 1700 mm
• Working pressure: 0.7 ÷ 0.8 Mpa
• Control system: solely pneumatic
• Supply: filtrated compressed-air (40 µm), not lubricated
• Noise level: <70 dB
• Max vertical lifting speed: 0,5 meters/second
• Working temperature: from +0° to +45° C
• Consumption: from 10 Nl ÷ 50 Nl per working cycle
• Rotations: – constant 360° on the column and tooling axis - 300° on the intermediate axis
